首页>产品型号>阀门>coax同轴阀MK20/FK20 <上一个
  • 产品照片
  • 产品照片
  • 产品照片

coax同轴阀MK20/FK20



最小起订货量

  • 无限制

您可能还关注相似产品
  • 主营产品|截止阀,调节阀,齿轮泵,限位开关等
  • 公司荣誉| 明星产品
供应产品分类
  • 暂无分类
本页信息为汉达森 高伟原厂生产的产品“coax同轴阀MK20/FK20”产品信息,如您想了解更多关于“coax同轴阀MK20/FK20”价格、型号、厂家的相关信息,请致电我们,或QQ在线交谈。
品牌coax 有效期至长期有效 最后更新2021-09-14 16:05
浏览次数4

coax同轴阀MK20/FK20

   coax同轴阀MK20/FK20

 压力范围 0-16 / 0-40 bar

高伟
QQ:2853369888  点击这里给我发消息
手机:17710704891
电话:010-64714988-215
传真:010-64714988-668
邮件:tk5@handelsen.cn
高伟邮箱:tk5@handelsen.cn电话:010-64714988-215 高伟微信二维码

  A B max. 40 bar

  B A max. 16 bar

  A C max. 40 bar

  C A max. 16 bar

  KV值 A B 14,1 m³/h

  A C 8,9 m³/h

  介质 气态  液态  高粘稠  凝胶状  高污染 


二位三通直动式

  MK / FK 32 DR

  特性



coax_meitu_22



  端口 螺纹 G 1 1/4 - G 1 1/2

  法兰 PN 16/40

  功能 NC



  流向 见压力范围

  开关周期 120 1/min

  开关时间 打开 440 ms





  关闭 250 ms

  介质温度 DC -20 °C — +100 °C

  AC -20 °C — +100 °C

  环境温度 DC -20 °C — +80 °C

  AC -20 °C — +80 °C

  重量 MK 18,0 kg

  FK 22,0 kg

  标称电压 Un 24 V DC

  Un 230 V 40-60 Hz AC

  驱动 DC 直流电磁铁

  AC 内置式整流器的直流电磁铁

  绝缘等级 H 180 °C

  防护等级 IP65

  负载率 ED 100%

  连接 按DIN EN175301-803标准的插头, 形式A 4个位置X90°, 电线直径 6-8 mm

  阀门的设计是基于介质和工况的要求.这些因素可能导致设计、密封材料和特性与通用参数表上的规格有所不同.
