SSP旋转凸轮泵S1-0005-H08适于各种液体应用
| 高艳春 QQ：2850590591 手机：15201542839 电话：010-64717020-122 传真：010-84786709-666 邮件：sales3@handelsen.cn |
 |
技术参数：
|
Pump Model |
Inlet & Outlet |
Displace- |
Differential Pressure |
Max. |
Weight Bare Shaft Pump |
|||||
|
Std Port Size |
Enlarged Port Size |
H |
V |
|||||||
|
mm |
in |
mm |
in |
L/rev |
bar |
psi |
rev/min |
kg |
kg |
|
|
S1-0005-*08 |
25 |
1 |
- |
- |
0.053 |
8 |
115 |
1000 |
15 |
16 |
|
S1-0008-*05 |
25 |
1 |
40 |
1.5 |
0.085 |
5 |
70 |
1000 |
17 |
18 |
|
S2-0013-*10 |
25 |
1 |
40 |
1.5 |
0.128 |
10 |
145 |
1000 |
28 |
30 |
|
S2-0013-*15 |
25 |
1 |
40 |
1.5 |
0.128 |
15 |
215 |
1000 |
28 |
30 |
|
S2-0018-*07 |
40 |
1.5 |
50 |
2 |
0.181 |
7 |
100 |
1000 |
29 |
31 |
|
S2-0018-*10 |
40 |
1.5 |
50 |
2 |
0.181 |
10 |
145 |
1000 |
29 |
31 |
|
S3-0027-*10 |
40 |
1.5 |
50 |
2 |
0.266 |
10 |
145 |
1000 |
53 |
56 |
|
S3-0027-*15 |
40 |
1.5 |
50 |
2 |
0.266 |
15 |
215 |
1000 |
53 |
56 |
|
S3-0038-*07 |
50 |
2 |
65 |
2.5 |
0.384 |
7 |
100 |
1000 |
56 |
59 |
|
S3-0038-*10 |
50 |
2 |
65 |
2.5 |
0.384 |
10 |
145 |
1000 |
56 |
59 |
|
S4-0055-*10 |
50 |
2 |
65 |
2.5 |
0.554 |
10 |
145 |
1000 |
105 |
111 |
|
S4-0055-*20 |
50 |
2 |
65 |
2.5 |
0.554 |
20 |
290 |
1000 |
105 |
111 |
|
S4-0079-*07 |
65 |
2.5 |
80 |
3 |
0.79 |
7 |
100 |
1000 |
110 |
116 |
|
S4-0079-*15 |
65 |
2.5 |
80 |
3 |
0.79 |
15 |
215 |
1000 |
110 |
116 |
|
S5-0116-*10 |
65 |
2.5 |
80 |
3 |
1.16 |
10 |
145 |
600 |
152 |
152 |
|
S5-0116-*20 |
65 |
2.5 |
80 |
3 |
1.16 |
20 |
290 |
600 |
152 |
152 |
|
S5-0168-*07 |
80 |
3 |
100 |
4 |
1.68 |
7 |
100 |
600 |
160 |
160 |
|
S5-0168-*15 |
80 |
3 |
100 |
4 |
1.68 |
15 |
215 |
600 |
160 |
160 |
|
S6-0260-*10 |
100 |
4 |
100 |
4 |
2.60 |
10 |
145 |
500 |
260 |
260 |
|
S6-0260-*20 |
100 |
4 |
100 |
4 |
2.60 |
20 |
290 |
500 |
260 |
260 |
|
S6-0353-*07 |
100 |
4 |
150 |
6 |
3.53 |
7 |
100 |
500 |
265 |
265 |
|
S6-0353-*15 |
100 |
4 |
150 |
6 |
3.53 |
15 |
215 |
500 |
2 |
|
