Specken-Drumag气动缸RP500简介



最小起订货量

  • 无限制

您可能还关注相似产品

  • 主营产品|
  • 公司荣誉|
供应产品分类
  • 暂无分类
本页信息为原厂生产的产品“Specken-Drumag气动缸RP500简介”产品信息,如您想了解更多关于“Specken-Drumag气动缸RP500简介”价格、型号、厂家的相关信息,请致电我们,或QQ在线交谈。
品牌Specken-Drumag 有效期至长期有效 最后更新2020-02-07 14:14
浏览次数8

Specken-Drumag气动缸RP500简介

吴亚男
QQ:2853369884  点击这里给我发消息
手机:17718583804
电话:010-64714988-212
传真:010-64714988-668
邮件:tk2@handelsen.cn
吴亚男邮箱:tk2@handelsen.cn电话:010-64714988-212

Specken-Drumag气动缸RP500简介

工作压力:1.5÷10 bar

环境温度:-20÷80°C。

流体:过滤空气,有或没有润滑。

桶:内部/外部阳极氧化铝和

孔:KD系列32÷125铝桶

系列K 160÷200,带圆形铝桶和钢制拉杆

嵌入式磁传感器DF ---- KD系列系列。

Specken-Drumag气动缸RP500简介

电线保护带磁传感器

适用于KD系列零件编号DHF-002100。

符合ISO 6431和VDMA 24562标准的UNIVER气缸,充分利用了过去几年的研究成果; 事实上,他们可以完全满足苛刻的用户。 使用非润滑空气的操作是值得的,因为它允许在许多工业部门中使用

保护环境。 强大的结构和选定的部件有助于赋予它们出色的操作性能和非常长的使用寿命。

嵌入式磁传感器DF ---- KD系列系列。

电线保护带磁传感器

适用于KD系列

磁传感器DH ---- K系列系列。

根据要求

- 塑性铁氧体中的磁环

- 锁定装置?32÷125 mm,仅可与镀铬钢棒系列KD

- 滑动装置?32÷100 mm

- 带有刚性衬套的气缸,串联,多位置和对置型

施工细节

采用挤压铝合金制成的清洁线桶,采用罗纹“抗扭”设计。内外表面阳极氧化至15微米。

铝合金压铸端盖采用自攻钢螺钉安装在机筒孔上。

气动可调缓冲垫提供有效的活塞减速。

合成橡胶减震器可避免机械应力并降低机械噪音(低于50 dB)。

采用乙缩醛树脂压铸铝合金活塞和导靴,带永久塑性铁氧体磁环(根据要求提供磁性版本)。

活塞和缓冲密封件由耐磨的丁腈橡胶复合材料制成,适用于有或没有的应用

润滑。双唇密封设计可自动自我补偿磨损。

硬化不锈钢棒(KD100系列)或镀铬(KD200系列),2微米Ra;提供坚果。

UNIVER原装自润滑自调心活塞杆衬套。对于特殊应用,可根据要求提供刚性衬套。气缸?125-160-200,提供标准的刚性活塞杆衬套。
